The Silent Knight 6808U is an addressable fire alarm control panel designed to monitor fire alarm initiating devices and manage notification appliances in a building fire alarm system. It supports addressable devices and conventional notification circuits, with programmable inputs and outputs for flexible system configuration.

The panel includes system status monitoring, alarm and trouble reporting, and expandable system capabilities for commercial fire protection applications.

Specifications:

Features:

• Complies with UL 864 10th Edition
• Built-in support for up to 159 SK detectors and 159 SK modules or 127 SD SLC devices
• Selectable strobe synchronization for Amseco, System Sensor, Wheelock, and Gentex devices
• 999 software zones and 999 output groups for flexible design options
• Four line LCD display with 40 characters per line
• Built-in USB interface for quick and easy programming
• JumpStart auto programming reduces installation time
