The SSU00457 SPACE AGE FR4 Fast Rail system delivers four integrated System Sensor modules engineered for advanced detection applications. Constructed from FR4 material, this rail assembly provides superior electrical insulation and thermal stability in demanding environments. The integrated edge protection safeguards components during installation and operation, reducing damage risk and extending service life. Fast Rail technology enables rapid module deployment and simplified system configuration, streamlining setup for technicians. Designed for professional-grade fire detection and safety systems, this four-module package offers reliable performance, scalability, and compliance with industry standards. Ideal for facilities requiring robust, modular sensor infrastructure.

Effortlessly install two to four System Sensor-style addressable modules using these convenient snap-in assemblies. Constructed from robust 20-gauge galvanized steel, the Fast Rails feature a variety of mounting hole configurations, allowing for flexible wall or cabinet placement. The 4” System Sensor-style addressable modules securely snap into position without the need for any tools. The FR2 model measures 9.125” in length, 4 5/16” in width, and 2 1/2” in depth, while the FR4 version is 18” long, 4 5/16” wide, and 2 1/2” deep.

Specifications:

Features:

• Secures System Sensor style 4” square addressable modules
• Spring loaded snap-in design
• 20 gauge galvanized steel construction
• Wire chase for vertical or horizontal installation
• Edge protector to eliminate wire cuts
• Mounting hole pattern for wall or cabinet mounting
